SA6R - ABIT
CPU 1. Supports Intel Pentium® II/!!! up to 1Ghz socket processor based on 100 & 133 MHz FSB 2. Supports Intel Celeron® up to 733Mhz socket processor based on 66 MHz FSB 3. Reserves support for future Intel Pentium® III/ Celeron socket processor Chipset 1. Intel 815E (ICH2) chipset 2. Supports 66/100/133MHz(Front Side Bus) 3. Supports AGP 1X/2X/4X (Sideband) 1.5/3.3V device. 4. Supports Advanced Configuration and Power Management Interface (ACPI) 5. Supports Ultra ATA/100,Ultra ATA/66,Ultra ATA/33 mode. Ultra DMA 100/RAID 1. High Point HPT370 IDE Controller 2. Ultra DMA 100MB/Sec data transfer rate 3. RAID 0(stripping mode for boosting performance) 4. RAID 1 (mirroring mode for data security) 5. RAID 0 +1(stripping and mirroring) Graphics 1. Chipset integrated AGP 2X 3D graphics acceleration. 2. Support AIMM (AGP In-line Memory Module) Memory 1. Four 168-pin DIMM sockets support SDRAM module 2. Supports up to 512MB MAX. ( 64, 128,256MB SDRAM) 3. Support 100MHz,133MHz SDRAM interface Audio 1. AC'97 2-channel Audio CODEC on board 2. Audio driver included System BIOS 1. CPU SOFT MENU™III technology and DIP switche funtion. 2. Award Plug and Play BIOS supports APM, DMI 3. Write-Protect Anti-Virus function by AWARD BIOS. Multi I/O Functions 1. 4 channels bus Master IDE Ports support Ultra DMA 33/66/100 (up to 4 devices) 2. PS/2 Keyboard and PS/2 Mouse Connectors 3. 1 Floppy Port (up to 2.88MB) 4. 1 Parallel Port (EPP/ECP) 5. 2 Serial Ports 6. 2 USB Connectors 7. On board USB header for two extra USB channels 8.1 standard 15 pin VGA connector. 9. Audio connector (Line-in, Line-out, Mic-in, and Game Port) Miscellaneous 1. ATX form factor 2. 1 Universal AGP slot, 6 PCI slots and 1CNR slot 3. Hardware Monitoring - Including Fan speed, Voltages, CPU and System temperature and one thermal header for other devices temperature monitoring 4. Keyboard and Mouse Power On 5. Built-in Wake on Lan / Wake on Modem header 6. Digital Video out interface supports digital display or TV out (Option) 7. Built-in IrDA TX/RX header CPU Support Compatibility RAM Memory Support Compatibility Manufacturer - downloads drivers, manuals and BIOS : ABIT Prodejce v ČR : Možnost vložení odkazu prodejce - info zde Recenze : Odkazy na recenze vložíme po dohodě Problems, experience, griffs.....: Problémy, zkušenosti, tipy, triky.....: |
|
